75
Chapter 3 Front-Panel Menu Operation
To Configure the Remote Interface
4
3
To Configure the Remote Interface
The Agilent 33500 Series supports remote interface communication
using a choice of three interfaces: GPIB, USB, and LAN (LXI Class C
compliant). All three interfaces are “live” at power up. The following
sections explain how to configure the remote interface from the
instrument front panel.
Note: Two CDs, provided with your instrument, contain connectivity
software to enable communications over the remote interfaces. See the
Agilent 33500 Series User’s Guide for further information on these CDs
and the software they contain.
GPIB Configuration (Option GPIB)
You need only select a GPIB address.
1 Select the “I/O” menu.
Press
and then press the
I/O Config
and
GPIB Settings
softkeys.
Then press the GP-IB Address softkey.
To Next Page
