74
Chapter 3 Front-Panel Menu Operation
To Store the Instrument State
3
• Standard file naming rules apply to state files.
• To add characters, press the right-cursor key until the cursor is to the
right of the existing name and then turn the knob.
• To use numbers in the name, you can enter them directly from the
numeric keypad.
3 Store the instrument state.
Press the STORE STATE softkey. A stored state contains the selected
function, frequency, amplitude, dc offset, duty cycle, symmetry, as well
as any modulation parameters in use. The instrument does not store
volatile waveforms created in the arbitrary waveform function.
4 Recall the instrument state (optional).
To restore (retrieve) a stored state, press
and then Store / Recall.
Then press Recall State, select the state to recall and press Select.
To Next Page
