Chapter 6 Service and Repair
Disassembly
4
6
Disassembly
For procedures in this manual, the following tools are required for
disassembly:
• T15 Torx driver (most disassembly)
• T8 Torx driver (front panel disassembly)
• Posidriv and flat bladed screw drivers
• 14 mm nut driver, hollow shaft (rear-panel BNC connectors)
• 7 mm nut driver (rear-panel GPIB connector)
WARNING SHOCK HAZARD. Only service-trained personnel who are aware
of the hazards involved should remove the instrument covers.
To avoid electrical shock and personal injury, make sure to disconnect
the power cord from the instrument before removing the covers. Some
circuits are active and have power applied even when the power switch is
turned off.
