Menu Example 3 Some commands in the menu require that you enter a numeric
parameter value. The following steps show you how to enter a number
in the menu. For this example, you will set the null value to –2.0 volts.
Make sure the multimeter is in the dc voltage function with 5
1
⁄
2
digits of
resolution displayed. Disconnect all inputs to the multimeter.
1 Turn on the menu.
You enter the menu on the “menus” level. The
MEAS MENU is your first
choice on this level.
A: MEAS MENU
2 Move across to the
MATH MENU choice on this level.
There are six menu group choices available on this level.
B: MATH MENU
3 Move down to the “commands” level within the MATH MENU.
The
MIN–MAX command is your first choice on this level.
1: MIN-MAX
4 Move across to the
NULL VALUE command on this level.
There are seven command choices available within the
MATH MENU.
2: NULL VALUE
>
∨
>
Shift <
On/Off
Chapter 2 Front-Panel Menu Operation
A Front-Panel Menu Tutorial
34
