Equipment Configuration Menu Descriptions
Press [ EQUIP CONFIG ] to display the
test equipment configuration and the
following softkeys:
[ AC CALIBRATO ]
Prompts you to enter the model, serial
number, GPIB address, and calibration
due date for the ac calibrator.
If you select [ Other ] for model, the
program prompts you to type in a
model, serial number, and calibration
due date but not an GPIB address.
When entering the calibration due date,
only four characters are displayed on
the screen. However, you can enter up
to nine characters and they will be
printed.
[ SYNTH. 1 ]
Prompts you to enter the model, serial
number, GPIB address, and calibration
due date for the synthesizer.
[ SYNTH. 2 ]
Prompts you to enter the model, serial
number, GPIB address, and calibration
due date for the second synthesizer. If
the first synthesizer is an HP 3326A or
if you are only performing the operation
verification tests, you do not need a
second synthesizer.
[ LOW-D. OSCILLATO ]
Prompts you to enter the model, serial
number, and calibration due date for the
low-distortion oscillator. If you have a
24.5 kHz notch filter or if you are only
performing the operation verification
tests, you do not need a low-distortion
oscillator.
[ MULTIMETER ]
Prompts you to enter the model, serial
number, GPIB address, and calibration
due date for the multimeter.
[ SAVE SETUP ]
Saves the current equipment
configuration to a file for future recall.
[ RECALL SETUP ]
Recalls an equipment configuration that
was previously saved using [ SAVE
SETUP ].
[ RETURN ]
Returns to the ITM_35670A main menu.
Verifying Specifications Agilent 35670A
3-52
