Agilent Technologies 35670A - Page 112

Performance Test Using Recommended Test Equipment Using Other Test Equipment
Measurement Uncertainty Ratio Measurement Uncertainty Ratio
Source Amplitude Accuracy
0.1 Vpk
3.0 Vpk
5.0 Vpk
± 9.83 mVpk
± 492.9 mVpk
± 633.0 mVpk
>10:1
>10:1
>10:1
Source Output Resistance
±0.15 Ω
>10:1
Source DC Offset
0 Vdc, 0 Vac-pk
±10 Vdc, 0 Vac-pk
0 Vdc, 5 Vac-pk
±5 Vdc, 5 Vac-pk
± 238 nV
± 84 mV
± 2.123 mV
± 43 mV
>10:1
>10:1
>10:1
>10:1
Source Flatness
± 0.2 dB
5.24:1
Source Distortion
fundamental <30 kHz
fundamental ≥30 kHz
±0.5 dB
±0.5 dB
6.3:1
>10:1
Verifying Specifications Agilent 35670A
Measurement Uncertainty
3-56
