Spurious Signals (continued)
Measurement Lower
Limit
Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
Four Ch, 9600 Hz Start, Ch 4 -80
Four Ch, 11200 Hz Start, Ch 1 -80
Four Ch, 11200 Hz Start, Ch 2 -80
Four Ch, 11200 Hz Start, Ch 3 -80
Four Ch, 11200 Hz Start, Ch 4 -80
Four Ch, 12800 Hz Start, Ch 1 -80
Four Ch, 12800 Hz Start, Ch 2 -80
Four Ch, 12800 Hz Start, Ch 3 -80
Four Ch, 12800 Hz Start, Ch 4 -80
Four Ch, 14400 Hz Start, Ch 1 -80
Four Ch, 14400 Hz Start, Ch 2 -80
Four Ch, 14400 Hz Start, Ch 3 -80
Four Ch, 14400 Hz Start, Ch 4 -80
Four Ch, 16000 Hz Start, Ch 1 -80
Four Ch, 16000 Hz Start, Ch 2 -80
Four Ch, 16000 Hz Start, Ch 3 -80
Four Ch, 16000 Hz Start, Ch 4 -80
Four Ch, 17600 Hz Start, Ch 1 -80
Four Ch, 17600 Hz Start, Ch 2 -80
Four Ch, 17600 Hz Start, Ch 3 -80
Four Ch, 17600 Hz Start, Ch 4 -80
Four Ch, 19200 Hz Start, Ch 1 -80
Four Ch, 19200 Hz Start, Ch 2 -80
Four Ch, 19200 Hz Start, Ch 3 -80
Four Ch, 19200 Hz Start, Ch 4 -80
Four Ch, 20800 Hz Start, Ch 1 -80
Four Ch, 20800 Hz Start, Ch 2 -80
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Performance Test Record - Four Channel
5 of 20
