Agilent Technologies 35670A Installation Guide

Channel Match
Measurement
Lower
Limit
Upper Limit Measured Value Pass/Fail
Two Ch, 2/1, 7 dBV FS Mag -0.04 0.04
Two Ch, 2/1, 7 dBV FS Phs -0.5 0.5
Two Ch, 2/1, -13 dBV FS Mag -0.04 0.04
Two Ch, 2/1, -13 dBV FS Phs -0.5 0.5
Two Ch, 2/1, -33 dBV FS Mag -0.04 0.04
Two Ch, 2/1, -33 dBV FS Phs -0.5 0.5
Two Ch, 2/1, 7 dBV -20 dBfs Mag -0.08 0.08
Two Ch, 2/1, 7 dBV -20 dBfs Phs -0.5 0.5
Four Ch, 2/1, 7 dBV FS Mag -0.04 0.04
Four Ch, 2/1, 7 dBV FS Phs -0.5 0.5
Four Ch, 2/1, -13 dBV FS Mag -0.04 0.04
Four Ch, 2/1, -13 dBV FS Phs -0.5 0.5
Four Ch, 2/1, -33 dBV FS Mag -0.04 0.04
Four Ch, 2/1, -33 dBV FS Phs -0.5 0.5
Four Ch, 2/1, 7 dBV -20 dBfs Mag -0.08 0.08
Four Ch, 2/1, 7 dBV -20 dBfs Phs -0.5 0.5
Four Ch, 3/1, 7 dBV FS Mag -0.04 0.04
Four Ch, 3/1, 7 dBV FS Phs -0.5 0.5
Four Ch, 3/1, -13 dBV FS Mag -0.04 0.04
Four Ch, 3/1, -13 dBV FS Phs -0.5 0.5
Four Ch, 3/1, -33 dBV FS Mag -0.04 0.04
Four Ch, 3/1, -33 dBV FS Phs -0.5 0.5
Four Ch, 3/1, 7 dBV -20 dBfs Mag -0.08 0.08
Four Ch, 3/1, 7 dBV -20 dBfs Phs -0.5 0.5
Four Ch, 4/1, 7 dBV FS Mag -0.04 0.04
Four Ch, 4/1, 7 dBV FS Phs -0.5 0.5
Four Ch, 4/1, -13 dBV FS Mag -0.04 0.04
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Four Channel
12 of 20
