Frequency Accuracy
Measurement Lower
Limit
(kHz)
Upper Limit
(kHz)
Measured Value
(kHz)
Pass/Fail
50 kHz 49.9985 50.0015
Anti-Alias Filter
Measurement Lower
Limit
Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
One Ch, Ch 1, 51.2 kHz -80
Two Ch, Ch 1, 51.2 kHz -80
Two Ch, Ch 2, 51.2 kHz -80
Four Ch, Ch 1, 25.6 kHz -80
Four Ch, Ch 2, 25.6 kHz -80
Four Ch, Ch 3, 25.6 kHz -80
Four Ch, Ch 4, 25.6 kHz -80
Input Coupling
Measurement Lower
Limit
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
dc - ac, Ch 1 3
dc - ac, Ch 2 3
dc - ac, Ch 3 3
dc - ac, Ch 4 3
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Four Channel
