Agilent Technologies 35670A Installation Guide

Measurement Lower
Limit
Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
Four Ch, F1-2F2, 24096 Hz, Ch 2 -80
Four Ch, F1-2F2, 24096 Hz, Ch 3 -80
Four Ch, F1-2F2, 24096 Hz, Ch 4 -80
Cross Talk
Measurement Lower
Limit
Upper Limit
(dBVrms)
Measured Value
(dBVrms)
Pass/Fail
Source-to-Ch 1 -126
Source-to-Ch 2 -126
Source-to-Ch 3 -126
Source-to-Ch 4 -126
Receiver Ch 1, Driver Ch 2, 3, 4 -126
Receiver Ch 2, Driver Ch 1, 3, 4 -126
Receiver Ch 3, Driver Ch 1, 2, 4 -126
Receiver Ch 4, Driver Ch 1, 2, 3 -126
Single Ch Phase Accuracy
Measurement Lower
Limit
(deg)
Upper Limit
(deg)
Measured Value
(deg)
Pass/Fail
Positive slope, Ch 1 -4 4
Positive slope, Ch 2 -4 4
Positive slope, Ch 3 -4 4
Positive slope, Ch 4 -4 4
Negative slope, Ch 1 -4 4
Negative slope, Ch 2 -4 4
Negative slope, Ch 3 -4 4
Negative slope, Ch 4 -4 4
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Performance Test Record - Four Channel
17 of 20
