Agilent Technologies 35670A Installation Guide

Measurement Lower
Limit
Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
One Ch, 87200 Start, Ch 1 -80
One Ch, 88800 Start, Ch 1 -80
One Ch, 97000 Start, Ch 1 -80
One Ch, 98600 Start, Ch 1 -80
One Ch, 100200 Start, Ch 1 -80
One Ch, 101800 Start, Ch 1 -80
A mplitude Accuracy
Measurement Lower
Limit
(dBVrms)
Upper Limit
(dBVrms)
Measured Value
(dBVrms)
Pass/Fail
-51 dBVrms, Ch 1 -51.15 -50.85
-51 dBVrms, Ch 2 -51.15 -50.85
-43 dBVrms, Ch 1 -43.15 -42.85
-43 dBVrms, Ch 2 -43.15 -42.85
-35 dBVrms, Ch 1 -35.15 -34.85
-35 dBVrms, Ch 2 -35.15 -34.85
-27 dBVrms, Ch 1 -27.15 -26.85
-27 dBVrms, Ch 2 -27.15 -26.85
-11 dBVrms, Ch 1 -11.15 -10.85
-11 dBVrms, Ch 2 -11.15 -10.85
1 dBVrms, Ch 1 0.85 1.15
1 dBVrms, Ch 2 0.85 1.15
9 dBVrms, Ch 1 8.85 9.15
9 dBVrms, Ch 2 8.85 9.15
19 dBVrms, Ch 1 18.85 19.15
19 dBVrms, Ch 2 18.85 19.15
27 dBVrms, Ch 1 26.85 27.15
27 dBVrms, Ch 2 26.85 27.15
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Operation Verification Test Record - Two Channel
6 of 10
