Flatness
Measurement Lower
Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
27 dBVrms, 99.84 kHz, One Ch, Ch 1 -0.2 0.2
9 dBVrms, 99.84 kHz, One Ch, Ch 1 -0.2 0.2
-11 dBVrms, 99.84 kHz, One Ch, Ch
1
-0.2 0.2
27 dBVrms, 51.2 kHz, Two Ch, Ch 1 -0.2 0.2
27 dBVrms, 51.2 kHz, Two Ch, Ch 2 -0.2 0.2
9 dBVrms, 51.2 kHz, Two Ch, Ch 1 -0.2 0.2
9 dBVrms, 51.2 kHz, Two Ch, Ch 2 -0.2 0.2
-11 dBVrms, 51.2 kHz, Two Ch, Ch 1 -0.2 0.2
-11 dBVrms, 51.2 kHz, Two Ch, Ch
2
-0.2 0.2
Amplitude Linearity
Measurement Lower
Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
13 dBVrms, Ch 1 -0.0615 0.061
13 dBVrms, Ch 2 -0.0615 0.061
-1 dBVrms, Ch 1 -0.105 0.104
-1 dBVrms, Ch 2 -0.105 0.104
-15 dBVrms, Ch 1 -0.33 0.318
-15 dBVrms, Ch 2 -0.33 0.318
-29 dBVrms, Ch 1 -1.551 1.316
-29 dBVrms, Ch 2 -1.551 1.316
-43 dBVrms, Ch 1 -13.823 5.088
-43 dBVrms, Ch 2 -13.823 5.088
-53 dBVrms, Ch 1 -30.116 10.896
-53 dBVrms, Ch 2 -30.116 10.896
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Operation Verification Test Record - Two Channel
7 of 10
