6-12 Agilent 4155C/4156C VXIplug&play Driver User’s Guide, Edition 4
Programming Examples for VEE Users
Programming Basics
To create output terminals in the To/From object
Figure 6-8 shows the Edit Function Panel dialog box of the hp4156b_spotMeas
function. These measurement transactions need the output terminals in the To/From
object. You can create the output terminal as shown in the following example.
1. Click the Parameters tab.
2. Enter the Name (output terminal name) for the output variable value.
3. Enter the Name (output terminal name) for the output variable status.
4. Click OK. The dialog box is closed, the transaction is added to the To/From
object, and the output terminals are created in the object.
The output terminal will be created with the default name if steps 2 and 3 are
omitted.
Figure 6-8 To Create Output Terminals
1
2
3
4
