Agilent Technologies 54835A User Manual

Chapter 1: General Information
Specifications & characteristics
1–7
Specifications & characteristics
The following tables list the performance specifications and operating characteristics for the
Agilent Technologies 54835A/45A/46A oscilloscope. Asterisks (*) denotes warranted
specifications, all others are typical. Specifications are valid after a 30 minute warm-up period,
and within
± 5 °C from the self-calibration temperature.
Acquisition
Maximum Sample Rate Real Time Agilent Models
54835A — 2-channel mode: 4 GSa/s
54835A — 4-channel mode: 2 GSa/s
54845A — 2-channel mode: 8 GSa/s
54845A — 4-channel mode: 4 GSa/s
54846A — 2-channel mode: 8 GSa/s
54846A — 4-channel mode: 4 GSa/s
Maximum Effective Sample Rate Equivalent Time 500 GSa/s
Memory Depth 2-channel mode: 65,536 points
4-channel mode: 32,768 points
Agilent 54835A, Agilent 54845A, and
Agilent 54846A
Memory Depth Modes Auto Optimized for best combination of
update rate and display quality.
Manual Selectable
2-channel mode: from 16 to 65,536
points
4-channel mode: from 16 to 32,768
points
Sampling Modes Real Time Successive single shot acquisitions.
Equivalent Time Random repetitive sampling (higher
time resolution at fast sweep speeds).
Filters 9-bit Bandwidth Limit filter: BW = (Sample Rate)/20
(Sin x)/x Interpolation: On/Off selectable FIR digital filter. Digital signal
processing adds points between acquired data points to enhance
measurement accuracy and waveform display quality.
BW= Sample Rate/4
Averaging Selectable from 2 to 4096.
