Chapter 6: Replacing Assemblies
To remove and replace the Option 200 sound card
6–19
To remove and replace the Option 200 sound card
Use this procedure to remove and replace the sound card.
1 Disconnect the power cable and remove the cover.
2 Remove the Torx T15 screw that secures the sound card to the rear of the chassis.
3 Pull the card up to disengage it from the motherboard, then up and out of the chassis.
CAUTION AVOID DAMAGE TO CABLES!
Be careful to not snag any of the cables.
4
To replace the card, reverse the removal procedure.
