Chapter 2: Preparing for Use
To tilt the oscilloscope upward for easier viewing
2–11
To tilt the oscilloscope upward for easier viewing
• If your oscilloscope has front feet with individual wire bails, lift up the front of the
oscilloscope, grasp one of the wire bails under the front corner, and pull it down and
forward until it latches into place. Repeat for the other wire bail.
• If your oscilloscope has front feet with a wire bail between the two feet, lift up the front
of the oscilloscope, grasp the bail near the center, and pull it down and forward until it
latches into place.
