Chapter 6: Replacing Assemblies
To remove and replace the motherboard
6–23
13
Once the WINBIOS has been configured, cycle power to start the Windows ’95
operating system and begin the plug-and-play driver installation. Note the following:
• Expect several iterations of the plug-and-play recognition and driver installation. Use the
Windows '95 drivers when available.
• Obtain the 548xx driver disk by contacting the Agilent factory. When Windows '95 finds
"Unknown PCI card" and displays the message "Insert Agilent Technologies 548XX Scope
Installation Disk", insert the floppy disk, select drive A:, and click OK to load the oscilloscope
driver.
• The instrument will reboot several times to recognize all of the hardware.
14
Run the self-test to verify the instrument is operating properly.
See "Self-Test Verification" in chapter 3.
