Chapter 7: Replaceable Parts
Replaceable Parts List
7–16
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
Exchange Assemblies
A13 54835-69527 1 4-CH ACQUISITION ASSEMBLY W/ATTENUATORS (Agilent Model 54835A)
A13 54845-69527 1 4-CH ACQUISITION ASSEMBLY W/ATTENUATORS (Agilent Model 54845A)
A13 54846-69527 1 4-CH ACQUISITION ASSEMBLY W/ATTENUATORS (Agilent Model 54846A)
External Chassis Parts
MP1 54801-47401 2 KNOB 12 MM GRAY
MP3 54801-47403 1 KNOB 24 MM GRAY
MP4 54801-47404 1 KNOB 12 MM YELLOW
MP5 54801-47405 1 KNOB 12 MM GREEN
MP6 54801-47406 1 KNOB 12 MM PURPLE
MP7 54801-47407 1 KNOB 12 MM PINK
MP8 54801-47408 1 KNOB 18 MM YELLOW
MP9 54801-47409 1 KNOB 18 MM GREEN
MP10 54801-47410 1 KNOB 18 MM PURPLE
MP11 54801-47411 1 KNOB 18 MM PINK
MP12 54810-44901 1 MOLDED-OVER HANDLE
MP13 54810-45001 2 END CAP - HANDLE
MP14 54810-68701 1 ACCESSORY POUCH
MP15 54815-94301 1 LABEL-KNOBS AND KEYS
MP16 54845-94304 1 LABEL BNC-4 CH (Agilent 548/35A/45A/46A - 1 M
Ω ≅ 12pF 100V Max)
MP17 54845-94305 1 LABEL-LOGO (Infiniium 1.5 GHz, 8 GSa/s) for 54845A
MP17 54835-94302 1 LABEL-LOGO (Infiniium 1.0 GHz, 4 GSa/s) for 54835A
MP17 54846-94305 1 LABEL-LOGO (Infiniium 2.25 GHz, 8 GSa/s) for 54846A
MP19 5041-9167 2 FOOT-BOTTOM (Old Version)
MP19 5041-9168 2 FOOT-BOTTOM NON-SKID (Old Version)
MP20 5042-1753 2 FOOT-REAR
MP21 C3751-60201 1 MOUSE
MP22 54810-85903 1 MOUSE PAD
MP23 E2610-60001 KEYBOARD (OPTIONAL ON SERIAL NUMBERS US37349999 AND BELOW)
MP38 1460-1345 2 TILT STAND (Old Version)
MP70 54810-61001 4 FOOT W/INSERT (New Version)
MP72 54810-03700 1 TILT STAND (New Version)
W1 8120-1521 1 CABLE-POWER (standard 125V USA)
W1 8120-1703 CABLE-POWER (Option 900-UK)
W1 8120-0696 CABLE-POWER (Option 901-AUSTL)
W1 8120-1692 CABLE-POWER (Option 902-EUR)
W1 8120-0698 CABLE-POWER (Option 904-250V USA/CANADA)
W1 8120-2296 CABLE-POWER (Option 906-SWIT)
W1 8120-2957 CABLE-POWER (Option 912-DEN)
W1 8120-4600 CABLE-POWER (Option 917-AFRICA)
W1 8120-4754 CABLE-POWER (Option 918-JAPAN)
Electrical Assemblies
A1 0950-3252 1 POWER SUPPLY
A2 2090-0396 1 COLOR FLAT-PANEL DISPLAY
A3 0950-3235 1 INVERTER-DISPLAY BACKLIGHT
