Chapter 7: Replaceable Parts
Replaceable Parts List
7–18
PC Motherboard Configuration 4 (AMI Motherboard w/120 MByte Floppy Drive)(serial prefix range US3919 through US3935 with
rear-panel label VIN # 025)
A4 54810-66524 1 PC Motherboard AMI Series 757 REV D (Atlas PCI-III)
A4A1 1821-4976 1 Microprocessor - AMD-K6-2/300MHz
A4A2-3 1818-7682 2 DRAM-SIMM 8MX32 (32 MB SIMM)
A4A4 0950-3399 1 Voltage Regulator Module (VRM) 2.2 V
A9 54810-68726 1 2.5" Hard Drv kit w/ Win98 Cert (compatible only w/AMI motherboards)
A10 0950-3931 1 3.5" LS-120 Floppy Disk Drive - 120 MByte
A15 0950-2064 1 Ethernet Adapter Card - ISA
A18 54810-66530 1 Adapter board w/ 2 connectors - 120 MB drive to ribbon cable
A19 1150-2091 1 Sound card - 16-bit ISA (Option 200 only)
MP60 54801-60102 1 Chassis assembly (compatible only w/AMI motherboard configurations)
W7 not used
W8 not used
W10 54801-61641 1 Cable - Display board to 120 MB floppy to 2.5" HDD
W22 54801-61637 1 Cable - PS/2 mouse connector assy
W23-25 54801-68701 1 AMI motherboard cable kit - serial and parallel cables
PC Motherboard Configuration 5 (FIC Motherboard w/120 MByte Floppy Drive)(serial prefix range US3949 and above with rear-
panel label VIN # 03X)
2
A4 54810-66534 1 PC Motherboard FIC VA-503A
A4A1 1821-4776 1 Microprocessor - AMD-K6-2/400MHz
A4A2 1818-8073 1 DRAM-DIMM 16MX32 (64 MB DIMM)
A9 54810-83520 1 2.5" Hard Drv w/ software installed (compatible only w/FIC motherboard
configuration)
A10 0950-3931 1 3.5" LS-120 Floppy Disk Drive - 120 MByte
A15 1150-2110 1 Ethernet Adapter Card - PCI 10/100Base-T
A18 54810-66531 1 Adapter board w/ 4 connectors - 120 MB drive to ribbon cables
A19 54810-66533 1 Sound riser card (for FIC motherboard configuration only)
MP60 54801-60103 1 Chassis assembly (compatible w/FIC motherboard configuration)
W7 not used
W8 not used
W10 54801-61643 1 Cable - A18 adapter board to 2.5" HDD
W22-25 54801-68706 1 FIC motherboard cable kit (serial, parallel, and PS/2 mouse cables)
W27 54801-61644 1 USB cable assy
2.Option 8ZE, remanufactured unit, may be an older configuration than indicated by the serial prefix
number. Refer to the rear-panel VIN # label, floppy drive and BIOS screen to determine the
configuration.
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
