Chapter 7: Replaceable Parts
Replaceable Parts List
7–20
H9 0515-1410 6 MS 3.0 X 0.50 20MM-LG PAN-HD T10
H10 0515-2195 4 MS M4 X 0.7 40MM-LG T15
H11 0515-2691 2 MS M2.6X0.45 6MM-LG PAN-HD T8
H12 0624-0633 7 SCREW-TGP 6-20 T15
H14 2190-0027 1 WIL.256 .478 .02
H15 2190-0068 1 WIL.505 .630 .02
H17 2950-0054 1 NUTH 1/2-28 .125
H18 2950-0072 1 NUTH 1/4-32 .062
H19 54801-24702 2 RETAINER-STRAP HANDLE
H20 54542-26101 1 GROUND LUG
H21 54503-25701 5 HEX NUT - FRONT PANEL BNC
H22 0515-1246 2 MS M3X0.5 6MM-LG PATCH LOCK T10
H23 0403-1052 1 STANDOFF/GUIDE - PC BRD
H24 0515-1763 2 SCR-THD-RLG M2x0.4 5MM-LG PAN-HD
H25 8160-1212 1 KEYBOARD GROUNDING SPRING
H26 5021-4302 4 M4x0.7 20MM-LG PAN-HD PATCHLOCK BLACK
H27 1401-0202 3 PROTECTOR CAP .234 ID .3125 DEPTH
H28 0515-1038 3 M3X.05MM 35 MM LG PANHD
H29 0380-1407 3 SPACER M3X25 MM
H30 0515-2219 3 MS 2.5X0.45 5 MM-LG FLAT-HD
MP37 1400-2120 2 ISA SLOT COVER
MP49 54801-00201 1 FRONT PANEL
MP50 54801-01205 1 LENS BRACKET
MP51 54801-01206 1 BRACKET-CAL BNC
MP52 54803-01705 1 SLEEVE, CABINET (2 FAN)
MP53 54801-04104 1 FRONT PANEL ASSY INSIDE COVER
MP54 54801-04102 1 AUTOPROBE PANEL - SNAP-IN (Older style)
MP54 54801-24701 1 AUTOPROBE PANEL (Newer style)
MP55 54801-04103 1 KEYBOARD CONNECTOR PLATE - REAR PANEL
MP56 54801-40502 1 FRONT FRAME
MP57 54801-01208 1 HARD DRIVE BRACKET-2.5" HD
MP60 See PC Motherboard Configurations earlier in this table.
MP61 54801-88001 1 LENS - DISPLAY
MP63 54815-41901 1 FRONT-PANEL KEYPAD-MAIN (4-CH) (Agilent 54835A/45A/46A)
MP64 54810-41902 1 KEYPAD-CURSOR
MP65 54803-44101 1 RF ABSORBER SHEET
MP66 54803-40605 1 SHIELD BNC GROUND
MP67 54801-47101 1 LENS GASKET
MP68 54801-47102 1 GASKET, KEYBOARD CABLE
MP69 54801-09101 2 AUTOPROBE PNL SNAP-IN CLIPS
MP73 54810-85401 0 INSULATOR-120 Mbyte FLOPPY DRIVE (only on upgraded units)
MP74 54801-01210 0 BRACKET-ADAPTER BOARD (only on upgraded units)
MP75 0403-1091 1 Bumper - Self adhesive
Cables
W2 54801-61605 1 CBL ASSY-POWER SUPPLY CONTROL
W3 54801-61603 1 CBL ASSY-5V POWER
W4 54801-61604 1 CBL ASSY-AUX.POWER
W5 54801-61607 1 CBL ASSY-PC POWER
W6 54801-61601 1 CBL ASSY-LINE SYNC
W7 See PC Motherboard Configurations earlier in this table.
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
