Agilent Technologies 54835A User Manual

3–27
Performance Test Record
Agilent Technologies
Agilent Technologies 54835A/45A/46A Oscilloscope
Model Number _____________________ Tested by___________________
Serial Number ___________________________ Work Order No.___________________
Recommended Test Interval - 1 Year/2000 hours Date___________________
Recommended next testing___________________ Ambient temperature ___________________
Test Limits Results
(Vmax - Vmin)/5 = Limits
dc Calibrator
Amplitude
1.000 0.998 to 1.002 ___________________
Input
Resistance
Channel 1 Channel 2 Channel 3 Chan 4/Ext
50
Ω 49.25 Ω to 50.75 Ω ___________ ___________ ___________ ___________
1 MΩ 990 kΩ to 1.010 MΩ ___________ ___________ ___________ ___________
Voltage
Measurement
Accuracy
Scale Coupling Supply Limits Channel 1 Channel 2 Channel 3 Channel 4
2 V/div 1 MΩ 5 V 4.836 V to 5.164 V ___________ ___________ ___________ ___________
1 V/div 1 MΩ 5 V 4.918 V to 5.082 V ___________ ___________ ___________ ___________
1 V/div 50Ω 5 V 4.918 V to 5.082 V ___________ ___________ ___________ ___________
500 mV/div 1 MΩ 3.5 V 3.459 V to 3.541 V ___________ ___________ ___________ ___________
500 mV/div 50Ω 3.5 V 3.459 V to 3.541 V ___________ ___________ ___________ ___________
200 mV/div 1 MΩ 1.4 V 1.384 V to 1.416 V ___________ ___________ ___________ ___________
200 mV/div 50Ω 1.4 V 1.384 V to 1.416 V ___________ ___________ ___________ ___________
100 mV/div 1 MΩ 700 mV 691.8 mV to 708.2 mV ___________ ___________ ___________ ___________
100 mV/div 50Ω 700 mV 691.8 mV to 708.2 mV ___________ ___________ ___________ ___________
50 mV/div 1 MΩ 350 mV 345.9 mV to 354.1 mV ___________ ___________ ___________ ___________
50 mV/div 50Ω 350 mV 345.9 mV to 354.1 mV ___________ ___________ ___________ ___________
20 mV/div 1 MΩ 140 mV 138.36 mV to 141.64 mV ___________ ___________ ___________ ___________
20 mV/div 50Ω 140 mV 138.36 mV to 141.64 mV ___________ ___________ ___________ ___________
10 mV/div 1 MΩ 70 mV 69.18 mV to 70.82 mV ___________ ___________ ___________ ___________
10 mV/div 50Ω 70 mV 69.18 mV to 70.82 mV ___________ ___________ ___________ ___________
Offset
Accuracy
Range Offset Limits Channel 1 Channel 2 Channel 3 Channel 4
200 mV/div 2.0 V 1.964 to 2.036 V ___________ ___________ ___________ ___________
100 mV/div 1.0 V 0.982 to 1.018 V ___________ ___________ ___________ ___________
50 mV/div 500 mV 491 to 509 mV ___________ ___________ ___________ ___________
