CI Maintenance 7
5977B Series MSD Operating Manual 207
1 Remove the CI source. (See “To Remove the CI Source” on page 211.)
2 Disconnect the green ground wire from the radiator. (See Figure 67.)
3 Use a T-10 Torx screwdriver to loosen the two retained screws that secure
the radiator to the analyzer and place the radiator in its storage container.
Figure 67 CI Source radiator
Green ground wire
Radiator
