7 General Maintenance
To Open the Rear Analyzer Chamber
200 7000/7010 Series TQ GC/MS Operating Manual
Figure 65. The rear analyzer chamber
Rear analyzer side plate
Detector board
Thumbscrews
Chamber closed
Collision cell
Rear analyzer
Detector
Rear side plate
Chamber open
