7 General Maintenance
To Replace the EM Horn
202 7000/7010 Series TQ GC/MS Operating Manual
9 Close the rear analyzer chamber. (See “To Close the Rear Analyzer
Chamber” on page 203.)
Figure 66. Replacing the EM horn (on a Series 2 detector)
Figure 67. EM horn for a Series 2 detector
Retaining clip
EM horn
Blue signal
wire
