SDN/ACC Specifications
10-1
Section 10: SDN/ACC
Specifications
SDN Specifications
Table 10-1: SDN Specifications
SDN System
Specifications
Value
Patients Up to 24 patients may be connected to the
SDN
Central Stations Up to 6 information centers may be
connected to the SDN.
Computer Systems Up to 2 computer systems may be
connected to the SDN
SDN Instrumentation Only compatible Agilent instruments may
be connected to the SDN
Instruments Connected to
a Branch
Up to 2 instruments may be connected to
each branch of the SDN (one patient per
branch) with a maximum of six “speedy
cards”
ACC Branch Wiring ACC Branches #1 through #24 are
dedicated for patient connected
instruments. Only one patient per branch.
ACC Branches #0, and #25 through #31 are
dedicated for non-patient connected
instruments (ICs and computer systems).
Wall Box Dimensions Only standard size, NEMA, single- or dual-
gang, switch wall boxes with conduit
knockouts (KOs) may be used. Minimum
depth = 7.0 cm (2.75 in.).
SDN Grounding The maximum difference in ground
potential between the third wire ground
delivered to an ACC and the third wire
ground delivered to any of its SDN
instruments, with the SDN system and local
distribution cables disconnected, is 500 mV
rms.
