To connect the optional keyboard
The analyzer may be connected to an optional external keyboard. The keyboard
remains active even when the analyzer is not in alpha entry mode.This
means that you can operate the analyzer using the external keyboard rather
than the front panel. Pressing the appropriate keyboard key does the same
thing as pressing a hardkey or a softkey on the analyzer’s front panel.
1 Set the power switch to on ( l ).
2 Connect the round plug on the keyboard cable to the KEYBOARD connector on
the analyzer’s front panel. Make sure to align the plug with the connector pins.
3 Connect the other end of the keyboard cable to the keyboard.
Preparing the Analyzer for Use
7-14
