Installation
Agilent Cary 60 Spectrophotometer User’s Guide 27
To access the Cary WinUV Help:
Click Start > Programs > Agilent > Cary WinUV > Cary Help or
press F1 on your keyboard with a Cary WinUV application open.
Cell Holder
A Microcell Holder is supplied as standard with the Cary 60. Follow
the instructions below to install and align it.
Figure 3. Cell holder base (left) and Microcell Holder
1. Locating holes 4. Microcell Holder thumbscrew
2. Cell holder base thumbscrew location 5. Cell lifter
3. Adjustment screw 6. Hexagonal ball driver (not shown)
Installation
To install the Microcell Holder:
1 Place a microcell in the Microcell Holder (if the cell has ground
glass sides or sides featuring the Cary logo, hold the cell by these
sides) and check that the cell aperture is vertically centered in
the cell holder aperture.
1
2
3
4
5
