Chapter 4 261
Instrument Functions: P - Z
System
Instrument Functions: P - Z
4.9.5.7.2 SCPI Socket
Turns on/off the capability of establishing Socket LAN sessions. This allows you to limit
SCPI access over LAN via socket sessions.
Key Path: System, SCPI Lan
State Saved: Survives Preset and power cycle, but not saved in Instrument State.
SCPI Status Bits/
OPC Dependencies: None
Factory
Default: On (Reset by
System, Restore Sys Defaults.)
Remote Command:
:SYSTem:COMMunicate:LAN:SCPI:SOCKet:ENABle OFF|ON|0|1
:SYSTem:COMMunicate:LAN:SCPI:SOCKet:ENABle?
Example: SYST:COMM:LAN:SCPI:SOCK:ENAB ON
4.9.5.7.3 SICL Server
Turns on/off the SICL server capability, enabling you to limit SCPI access over LAN via the
SICL server. (SICL IEEE 488.2 protocol.)
Table 4-1 SCPI Default Settings
Parameter Description Setting
Maximum Connections The maximum number of connections that can be accessed
simultaneously
5
Instrument Name The name (same as the remote SICL address) of your
analyzer
inst0
Instrument Logical Unit The unique integer assigned to your analyzer when using
SICL LAN
8
Emulated GPIB Name The name (same as the remote SICL address) of the device
used when communicating with your analyzer
gpib7
Emulated GPIB Logical Unit The unique integer assigned to your device when it is being
controlled using SICL LAN
8
Emulated GPIB Address The emulated GPIB address assigned to your transmitter
tester when it is a SICL server (the same as your GPIB
address)
18
