Parts and Materials 5
1100 Series WS MWS Reference Manual 167
Injection-Valve Assembly
Tabl e 25 Injection-Valve Assembly
Item Description Part Number
1 Injection-valve assembly, includes items 1 – 6 0101-0921
2 Isolation seal 0100-1852
3 Rotor seal (Vespel) 0100-1853
3 Rotor seal (Tefzel) 0100-1849
4 Stator face 0100-1851
5 Stator head 0100-1850
6 Stator screws 1535-4857
Table 26 Micro Injection-Valve Assembly
The Micro injection valve assembly has no ceramic stator face.
Item Description Part Number
1 Micro injection-valve assembly, incl. items 1 - 2- 3 - 5 - 6 0100-1050
2 Isolation seal 0100-1852
3 Micro Rotor seal (Vespel) 0100-2088
5 Micro stator head 0100-2089
6 Stator screws 1535-4857
