Agilent Technologies G1367A

Installing the Sampler 1
1100 Series WS MWS Reference Manual 21
Figure 2 Recommended Stack Configuration - Well-plate Sampler (Rear View)
GPIB or LAN
to LC ChemStation
Analog signal to
recorder
Remote cable
CAN Bus cable
AC power
Analog signal to
recorder
