Agilent Technologies G1367A

Installing the Sampler 1
1100 Series WS MWS Reference Manual 23
Figure 4 Recommended Stack Configuration - Thermostatted Sampler (Rear View)
GPIB or LAN to
LC
ChemStation
Analog signal
to recorder
AC power
Remote
cable
CAN bus cable
Autosampler -
Thermostat cable
AC power
Analog signal
to recorder
