Verification and Calibration Appendix B
Series N6700 User’s Guide 153
Step 6. Measure the output voltage with the DVM and enter the data.
Front Panel: SCPI Command:
Select the Measured Data field. Enter
the data from the external DVM.
Press Select when done.
Press Next to finish calibration.
CAL:DATA <data>
Low Range Voltage Programming Calibration
This only applies to Agilent Models N6761A and N6762A.
Step 7. Select the low-voltage programming range. This example selects the 5
volt programming range of channel 1. The value to program a range
must be the maximum voltage of the range.
Front Panel: SCPI Command:
Select
System\Admin\Cal\Function\Vprog.
Then select the Low range.
CAL:VOLT 5
, (@1)
Step 8. Select the first voltage calibration point.
Front Panel: SCPI Command:
Select Next. The information field
should indicate: Enter P1 data
CAL:LEV P1
*OPC?
Step 9. Measure the output voltage with the DVM and enter the data.
Front Panel: SCPI Command:
Select the Measured Data field. Enter
the data from the external DVM.
Press Select when done.
CAL:DATA <data>
Step 10. Select the second voltage calibration point.
Front Panel: SCPI Command:
Select Next. The information field
should indicate: Enter P2 data
CAL:LEV P2
*OPC?
Step 11. Measure the output voltage with the DVM and enter the data.
Front Panel: SCPI Command:
Select the Measured Data field. Enter
the data from the external DVM.
Press Select when done.
Press Next to finish calibration.
CAL:DATA <data>
