Chapter 14 105
Baseband I/Q Inputs (Option BBA) Measurement Concepts
Selecting Input Probes for Baseband Measurements
Supported Probes
The following table lists the probes currently supported by Option BBA:
Probes without Stored Calibration
The following 115xA active probes may be used with the MXA’s
baseband IQ inputs and may use the same probe calibration utility
software. However, the probe calibration data is not stored in the MXA
and will be lost if power is cycled. Use of the E2655B de-skew and
calibration kit, including the calibration fixture, is required because of
the different physical configuration of the probes. (The physical
connections are different mechanically, not electrically.)
Refer to the current Agilent probe data sheet for specific information
regarding frequency of operation and power supply requirements.
Table 14-1
Probe Type Model Number Description
Active 1130A 1.5 GHz differential probe amp
(No probe head)
1131A
a
InfiniMax 3.5 GHz probe
1132A
a
InfiniMax 5 GHz probe
1133A
a
InfiniMax 7 GHz probe
Passive 1161A Miniature passive probe, 10:1, 10 MΩ,
1.5 m
a. Probe heads are necessary to attach to your device properly.
Probe connectivity kits such as the E2668A, E2669A or
E2675A are needed. For more details, refer to the Agilent
probe configuration guide, 5968-7141EN and 5989-6162EN.
Table 14-2
Probe Type Model Number Description
Active 1153A 200MHz differential probe
1156A Active probe, 1.5 GHz
1157A Active probe, 2.5 GHz
1158A Active probe, 4 GHz
