Agilent Technologies N9020A - Setting the BTS (Example)

86 Chapter 11
IQ Waveform (Time Domain) Measurements
Setting the BTS (Example)
Setting the BTS (Example)
From the base transmission station simulator and the system
controller, set up a call using loopback mode for the BTS to transmit the
RF power as follows:
Frequency: 2.0 GHz
Output Power: −20 dBm
Carrier Number: 1
Switching Point: 3
Scramble Code: 0
Table 11-1 Timeslot Setup
Timeslot State
0On
1On
2On
3On
4Off
5Off
6Off
DwPTS On
UpPTS Off
