70 Chapter 9
Modulation Accuracy (Composite EVM) Measurements
Measurement Results
Measurement Results
The Mod Accuracy I/Q Polar Vector Constellation measurement result
should look similar to Figure 9-3.
The modulation constellation is shown, along with summary data for
Rho, EVM, Peak Code Domain Error, and phase and magnitude errors.
Figure 9-3 Modulation Accuracy - I/Q Measured Polar Graph View
(Default)
Figure 9-3 shows a combination view of the code domain power graph
and metrics windows.
Figure 9-4 Modulation Accuracy - Code Domain Power View
