9
1 Making TD-SCDMA with
HSPA/8PSK Measurements
This chapter begins with instructions common to all measurements,
then details all the measurements available by pressing the
Meas key
when the
TD-SCDMA with HSPA/8PSK mode is selected.
NOTE If you only install Option N9079-1FP, press TD-SCDMA to select the
TD-SCDMA mode.
If you install both Option N9079-1FP and Option N9079-2FP, press
TD-SCDMA with HSPA/8PSK to select the TD-SCDMA mode.
For information specific to individual measurements, see the sections at
the page numbers below.
• “Transmit Power Measurements” on page 13
• “ACP Measurements” on page 21
• “Power vs. Time Measurements” on page 29
• “Spectrum Emission Mask Measurements” on page 37
• “Spurious Emissions Measurement” on page 45
• “Occupied Bandwidth Measurements” on page 51
• “Power Statistics CCDF Measurements” on page 57
• “Code Domain Measurements” on page 73
• “Modulation Accuracy (Composite EVM) Measurements” on page 65
• “IQ Waveform (Time Domain) Measurements” on page 83
• Chapter 12 , “Monitor Spectrum Measurements,” on page 89
