Agilent Technologies U3402A User Manual

Specifications and Characteristics 6
U3402A User’s and Service Guide 91
Function Rate Range Resolution
Maximum
reading
Accuracy
(One year; 23ºC
± 5ºC)
Typical input
impedance
[1]
Burden voltage
[4]
Current
Slow
12.0000 mA
120.000 mA
1200.00 mA
12.0000 A
0.0001 mA
0.001 mA
0.01 mA
0.0001A
11.9999
119.999
1199.99
11.9999
0.05% + 15
[2]
0.05% + 5
0.2% + 5
0.2% + 5
—
< 0.15 V
< 1.5 V
< 0.3 V
< 0.6 V
Med
40.000 mA
120.00 mA
1200.0 mA
12.000 A
0.001 mA
0.01 mA
0.1 mA
0.001 A
39.999
119.99
1199.9
11.999
0.1% + 6
0.1% + 3
0.2% + 3
0.2% + 3
—
< 0.5 V
< 1.5 V
< 0.3 V
< 0.6 V
Fast
40.00 mA
120.0 mA
1200 mA
12.00 A
0.01 mA
0.1 mA
1 mA
0.01 A
39.99
119.9
1199
11.99
0.1% + 2
0.1% + 2
0.2% + 2
0.2% + 2
—
< 0.5 V
< 1.5 V
< 0.3 V
< 0.6 V
Diode/
Continuity
Slow — 0.00001 V 1.19999 V 0.012% + 5 — —
Med — 0.0001 V 2.4999 V 0.012% + 5 — —
Fast — 0.001 V 2.499 V 0.012% + 2 — —
Resistance
/
Continuity
(2-wire)
Slow 120.000 W 0.001 W 119.999 0.1% + 8
[5]
——
Med 400.00 W 0.01 W 399.99 0.1% + 5
[5]
——
Fast 400.0 W 0.1 W 399.9 0.1% + 2
[5]
——
Table 6 - 1 DC resolution, full scale reading, and accuracy [±(% of reading + count)] (continued)

Agilent Technologies U3402A Specifications

General

Brand	Agilent Technologies
Model	U3402A
Category	Multimeter
Language	English
