Agilent Technologies U3402A

6 Specifications and Characteristics
106 U3402A User’s and Service Guide
Table 6 - 11 Reading rates for the dual display (readings/second (approx))
Measurement functions Slow Medium Fast
DCV / ACV
0.8 1.1 1.6
DCA / ACA
0.5 0.7 0.9
DCV / DCA
0.7 1.1 1.6
DCV / ACA
0.1 0.4 0.5
ACV / ACA
0.1 0.4 0.5
ACV / DCA
0.8 1.1 1.6
ACV / Frequency
[1]
1.0 1.7 2.3
ACA / Frequency
[1]
1.2 1.7 2.5
ACV + DCV / DCV
0.7 1.1 1.6
ACA + DCA / DCV
0.1 0.3 0.4
ACA + DCA / ACV
0.1 0.3 0.4
ACA + DCA / DCA
0.5 0.7 0.9
dBm (ACV) / Reference
2.2 5.5 22.0
dBm (ACV) / ACV
2.2 4.3 11.0
dBm (ACV) / DCV
0.8 1.1 1.8
dBm (ACV) / Frequency
[1]
1.0 1.7 2.4
Notes:
1 This reading rate depends on the frequency of the signal, the table itself shows the worst
possible case.
2 This table shows the typical combinations of measurement functions for the dual display.
