1Getting Started
6 U3402A User’s and Service Guide
Adjusting the Handle
To adjust the handle, grasp the handle by the side and pull outward. Then,
rotate the handle to the desired position. Figure 1- 2 below shows the possible
handle positions.
Figure 1-2 Type of handle position
To attach or detach the handle, rotate the handle upright and pull it out from
the sides of the multimeter. Refer to Figure 1- 3.
Figure 1-3 Attaching and detaching the handle.
Benchtop
position
Carrying position
Handle removal position
