6 Specifications and Characteristics
108 U3402A User’s and Service Guide
Storage Compliance
• – 20 °C to 60 °C
• Relative humidity at 5% to 90% RH (non-condensing)
Safety Compliance
• IEC 61010-1:2001/EN61010-1:2001 (2nd Edition)
• Canada: CAN/CSA-C22.2 No. 61010-1-04
• USA: ANSI/UL 61010-1:2004
EMC Compliance
• IEC 61326-1:2005/EN61326-1:2006
• Canada: ICES/NMB-001:2004
• Australia/New Zealand: AS/NZS CISPR11:2004
Shock and Vibration
• Tested to IEC/EN 60068-2
I/O Connector
• Output connectors
I/O Interface
• RS232 (For calibration use only)
Dimension (HxWxD)
• 226.00 × 105.00 × 305.00 mm (with bumpers)
• 215.00 × 87.00 × 282.00 mm (without bumpers)
Weight
• 3.44 kg (with bumpers)
Warm Up Time
• 30 minutes
Calibration Cycle
• One year
Warranty
• One year
• Three months for standard shipped accessories
Table 6 - 12 General characteristics
