Single-wheel power hoe 2100 23
Starting the Engine
W
Do not start engine in closed rooms!
Exhaust fumes contain carbon monoxide
which acts toxic when inhaled.
Protective covers mounted?
Tilling tool attached correctly?
Mount spark plug connector.
Air filter clean? Check engine oil level.
Fuel quantity in tank sufficient?
Open the fuel tap.
Cold engine:
Press tickler (B/23) on carburetor until fuel overflows.
Warm engine:
Do not actuate tickler on carburetor.
Pull the clutch lever and safety circuit shift lever
in start position.
Flick the engine shut-off switch to “I”.
Cold engine:
Move the speed control lever to max. (full throttle).
Warm engine:
Move the speed control lever to 1/4 throttle.
Start engine from a position outside the hazar-
dous area
Pull the starter rope on the handle until the starter
clutch engages. Then pull hard and fast to pull the
rope all the way out. After the start, let the rope glide
back. Do not let it snap back.
Do not touch the hot engine - danger of burns!
Do not touch the ignition cable and do not
touch or remove ignition spark connector
while the engine is running.
4. Commissioning and Operation
4
28
? ok
? ok
1/4
max.
B/23
