4 Single-wheel power hoe 2100
Designation of Parts
Figure A and B
1 Fuel tank
2 Fuel tank cap
3 Gear shift lever
4 Handlebar
5 Tool kit
6 Tensioning lever for handlebar side adjustment
7 Hexagonal screw for handlebar height adjustment
8 Oil bath air filter
9 Spark plug
10 Cooling-air baffle
11 Location for front weight mounting and engine hoop guard
12 Exhaust
13 Drive-wheel
14 Cap for clutch and chain gear housing
15 Tilling attachment
18 Square nut for handlebar height adjustment
19 Shift lever for tilling drive
20 Name plate/ID No.
21 Fuel tap
22 Carburetor
23 Carburetor - tickler
24 Engine No.
25 Spark plug/spark plug connector
26 Tensioning lever for protective hood
27 Tensioning spring for protective hood
28 Mechanical gearbox – oil filler screw/oil control screw
29 Starter handle
30 Tilling drive
31 Cooling-air screen
32 Drive-wheel
33 Hexagonal nut for drive-wheel
