Agria 400P - Fuel Tap and Clutch Operation

agria Multi-Purpose Machine 400P 17
3. Devices and Operating Elements
3
Fuel tap
The fuel tap (B/13) is on the carburetor.
 Move the tap to the right to open it.
 Move the tap to the left to close it.
Clutch
The multi-purpose machine is equipped with a V-
belt clutch with integrated reverse shift. Operation
is via the clutch lever (C/5).
The machine is decoupled when you pull the clutch
lever until pawl locks into place. Now, the engine
stops driving the machine. The clutch lever can be
locked with pawl (C/6) when the machine is
decoupled.
To avoid clutch slipping away during operation, a
clutch play is factory-set at the clutch lever (refer to
“Maintenance”).
After the first operating hour, the clutch play has to
be checked and, if necessary, re-adjusted (refer to
“Maintenance”).


B/13
C/5
C/6
