Agria 400P - Steering Handle Adjustment

26 agria Multi-Purpose Machine 400P
3. Devices and Operating Elements
H
G
3
Steering Handle
Steering handle height adjustment
l Remove the knob screw (2) from the
square clamping piece (3) and remove
it from the steering bar joint.
l Adjust the steering handle to the de-
sired height and fit it into proper boring
of the steering bar joint.
l Insert the knob screw and bolt it
down to the clamping piece (3). (En-
sure that nose of clamping piece (3)
locks into the long hole the steering bar
joint).
Steering handle side adjustment
l Loosen knob screw (1) until all
notches are free.
l Swivel the steering handle to the
desired position and fit into proper
notch.
l Re-tighten knob screw.
