agria Multi-Purpose Machine 400P 19
3. Devices and Operating Elements
3
Figure: V-belt is in “speed I” position.
On the V-belt guard to the left there is a
small window to monitor the current
speed, i.e. on which pulley the belt is
currently running.
Recommended speeds
Wheel drive
The multi-purpose machine is equipped
with drive-wheel engagement and a
wheel drive. This can be engaged/dis-
engaged via a selector sleeve and from
the handlebar.
Wheel drive engaged:
Move wheel drive lever (C/11) down to
unlock the pawl.
Wheel drive disengaged:
Move wheel drive lever (C/11) up to lock
the pawl.
With the engine running, the wheel drive
is engaged the following way:
l Pull the clutch lever (C/5) to middle
position (neutral) and hold.
l Unlock pawl (C/10).
l Move hand lever for wheel drive
(C/11) down.
l Slowly release the clutch lever (C/5)
while pressing the throttle.
In case wheel drive cannot be engaged,
couple and decouple. Then engage
wheel drive.
I Pto-driven
attach-
ments
C/11
C/10
Rotary snow
cleaner, mowing,
sweeping,
spreading,
shredding, spray-
ing, ploughing
II Surface work
not pto-driven
Snow dozing,
transport work
III Rotary
cultivation
Hoeing, ridging
