www.aim-sportline.com - PDM 32 User Guide 21
• click “New” and a new configuration panel appears: please, select “PDM32”.
Now you must follow the TABS to configure all the aspects of the PDM32:
Channels: to configure all the digital, analog and internal inputs
to configure all the digital, analog and internal inputs
To select the protocol for connecting your PDM32 to the ECU of the vehicle
To select the protocol for communicating with other devices through the CAN 2
To manage other AIM devices, such as:
RIO 02 https://www.aim-sportline.com/download/technical-sheets/aim_rio02_102.pdf
GPS08 https://www.aim-sportline.com/en/products/gps08-module/index.htm
SmartyCam https://www.aim-sportline.com/en/products/smartycam-hd-rev2.1/index.htm
In case you need to produce a channel that is a mathematical computation of other channels
In case you need to manage a Boolean channel depending upon other channels and inputs
General purpose parameters
Only if a display is connected
A way for activating some special functionalities, such as page change, alarm shut etc.
Power outputs configuration
Configuration of the CAN out messages
Configuration of the data to be transmitted to the SmartyCam
https://www.aim-sportline.com/en/products/smartycam-hd-rev2.1/index.htm
11.1 Channels and Variables
The activity of the PDM is based on the value of a whole series of variables, which can be divided in:
- Input channels: i.e. both analog and digital values, dependent on sensors or buttons, which can be directly
connected to the inputs or via CAN connections
- Status variables, i.e. variables, defined by the user, which assume different status based on configurable
formulas
- Power Outputs. Activations towards the outputs, based on the defined conditions, the value of the status
variables and the input channels.
