Aiphone IX SERIES Web Setting Manual

108
Configuring the Station
How to configure Daily Schedule
Configure the time at which relay output will be performed, in units of one day. A schedule one year from the set day
can be configured. 12 schedules can be set for each day.
1. Select the day for which to set a schedule from "Calendar."
2. Configure the "Start Time" and "End Time," and then click [Add].
3. When done, click [Update].
■ Start Time
Description Set the time when contact output starts.
Settings 00:00 - 23:59
Default values -
Calendar
Set schedule list

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
