LogiCool InRak™
IT Cooling
70
InRak™ Technical Manual 7462807 V1.11.0_04_2016
Installation
TS
TCE
PT
TS
5
16
"
5
16
"
5
16
"
PT
M
PSL
TS
PT
PSH
5
16
"
5
16
"
5
16
"
5
16
"
DISCHARGE LINE
CONDENSER
COIL
LOCATED EXTERNALLY
LIQUID LINE
LIQUID EXPANSION
LINE
EVAPORATOR
ASSEMBLY
VARIABLE SPEED
SCROLL
COMPRESSOR
SUCTION LINE
OIL FEED
LINE
KEY: ALL ITEMS
TCE
PT
PSL
TS
PSH
M
5
16
"
NORMALLY CLOSED SOLENOID
VALVE
ELECTRONIC EXPANSION VALVE
SIGHT GLASS
FILTER DRIER
(SUPPLIED LOOSE)
CENTRIFUGAL FAN
AXIAL FAN
SCROLL COMPRESSOR
NORMALLY OPEN SOLENOID
VALVE
SCHRADER VALVE
(SIZE SHOWN INDIVIDUALLY ON
EACH VALVE)
SHUT OFF VALVE
(OPTIONAL - SUPPLIED LOOSE)
PRESSURE TRANSDUCER
LOW PRESSURE SWITCH
HIGH PRESSURE SWITCH
TEMPERATURE SENSOR
CHECK VALVE
OIL SEPARATOR
Installation
Pipework Schematics
X1
The liquid line
lter drier must be
installed as close to
the indoor unit as
possible.
