Operation
Started By Operation start signal
- “External”, using external contacts
and relays.
- “Airlinq”, manual start using a
control panel.
- “CO2”, using a CO2 sensor.
- “PIR”, using a passive infrared
sensor.
- “BMS”, using an analogue or digital
BMS system.
- “Timer”, using a timer.
- “Holiday mode”, via control panel or
a digital BMS system.
- “Dependent”, on several start
signals.
Operation State Operation status
- “Automatic”, fully automatic opera-
tion according to programming.
- “Manual”, when the automatically
set air ow or inlet temperature
is changed by the user or a BMS
system.
- “Night time cooling” is activated.
- “Holiday mode” is activated.
- “OFF”, the unit is switched o, and
must be started using the control
panel.
- “Standby”, the unit is temporarily
stopped and will start automatically
according to programming.
System Condition Active internal control system
function
- “Low temperature”.
- “High temperature”.
See “Internal control functions” on page 26.
Ext. Emergency Stop Emergency stop function
status On/O.
Inlet Temperature Inlet temperature in °C.
Outside Temp. AHU Outside temperature air
handling unit in °C.
Room Temperature Extraction temperature in °C.
Exhaust Temp. AHU Exhaust temperature air
handling unit in °C
Requested Temp. Setpoint Inlet temperature in
°C.
Operation
Max Room Temp. Setpoint “High room tem-
perature” in °C.
Pre Heater Connected in %.
Comfort Heater Connected in %.
Main Damper Status On/O.
Bypass Damper Bypass position in %. (0 =
closed; 100 = fully open)
Adaptive Inlet Signal voltage adaptive inlet
in Volts.
Supply Fan Signal voltage supply fan in
Volts.
Extraction Fan Signal voltage extraction fan
in Volts.
Cooling Module Operation in %.
Evaporator temp. Evaporator temperature in °C.
Condenser temp. Condenser temperature in °C.
Setpoint Cooling Mod. Cooling module temperature
setpoint in °C.
Outside Temperature Outside temperature cooling
module in °C.
Evaporator in Evaporator temperature “in”
in °C.
Evaporator out Evaporator temperature “out”
in °C.
Hot Gas Hot Gas temperature in °C.
Rel. humidity outside Relative humidity (outside
air) in %
Rel. humidity inside Relative humidity (exhaust
air) in %
AI#1 Analogue input 1 in Volts.
AI#2 Analogue input 2 in Volts.
AI#3 Analogue input 3 in Volts.
NB! If an option is not installed, no operation value
will show in the status menu.
