AIRSYS 13E1C3 - Summary Electrical Ratings (Wire Sizing)

Chapter 2: Installation
Required Materials
Page 11
No.
Item
Qty
Description
Comments
14
Breakers for AC power
panel
3
One 10 amp circuit breaker for ASLLC.2;
One circuit breakers each for the two
WPUs AC part, amperage based on
model number
Refer to Table 6: WPU Electrical
Ratings on page 11
15
Breakers for DC power
panel
(only if ASLLC.2.48 is
chosen and the HVAC is
equipped with DC EC
supply fan)
3
One 10 amp circuit breaker for
ASLLC.2.48;
One circuit breaker each for two WPUs
DC part, amperage based on model
number
Refer to Table 6: WPU Electrical
Ratings on page 11
Summary Electrical Ratings (Wire Sizing)
Table 6: WPU Electrical Ratings
ELECT. HEAT
1.5 KW
2.4kW
5 KW
AC
48VDC
AC
48VDC
AC
48VDC
Model
MCA
MFS
MCA
MFS
MCA
MFS
MCA
MFS
MCA
MFS
MCA
MFS
AC Supply Fan, Single Phase AC Power Supply
M-
OD
3R1C1DR410.230/1/60.AC
10
15
--
--
15
20
--
--
--
--
--
--
5R1C1DR410.230/1/60.AC
11
15
--
--
15
20
--
--
--
--
--
--
7E1C2DR410.230/1/60.AC
--
--
--
--
17
25
--
--
31
35
--
--
9E1C2DR410.230/1/60.AC
--
--
--
--
--
--
--
--
31
35
--
--
13E1C3DR410.230/1/60.AC
--
--
--
--
--
--
--
--
32
40
--
--
18E1C4DR410.230/1/60.AC
--
--
--
--
--
--
--
--
37
55
--
--
DC Supply Fan, Single Phase AC Power Supply
M-
OD
9E1C2DR410.230/1/60.DC
--
--
--
--
18
30
7
10
28
35
7
10
13E1C3DR410.230/1/60.DC
--
--
--
--
--
--
--
--
28
40
14
20
DC Supply Fan, Three Phase AC Power Supply
M-
OD
13E1C3DR410.230/3/60.DC
--
--
--
--
--
--
--
--
17
25
14
20
Note: This chart should be used as a general guideline for estimating the conductor size and over-current protection.
Always refer to the data label on the unit for sizing the conductors and over-current protection.
MCA = Minimum Circuit Ampacity (Wire Size Amps). MFS = Maximum Fuse Size or HACR circuit breaker.
